Product Specifications
BASIC INFORMATION
Operating System: Google TV
Storage: 32GB
Languages: English, Vietnamese, Thai, Chinese, Russian,
Arabic, Traditional Chinese, Indonesian, French, Spanish (Latin America),
Farsi, Mongol, Uzbek, Hebrew.
TV System: ATV: Auto/PAL/NTSC DTV: DVB-T MPEG2/MPEG4 DVB-T
Compatible
AV System: PAL, NTSC
HDMI & HDCP Version: HDMI1.4b, HDMI2.0, HDMI2.1, HDCP1.4
& HDCP2.2
HDR: HDR10+ & Dolby Vision IQ
Power Supply: AC 100V-240V 50/60Hz
Power Consumption (Standby): ﹤0.5W
Star Rating: 3.5 Star
CEC: 476 Kwh
ECO Energy Efficiency: Yes
LED Indicator: Standby indicator (white) Mic indicator
(coloured)
BASIC FUNCTION
Google Assistant/Voice Search: Voice input via voice remote
control (RC902V). Hands-free voice input via built-in MIC.
Instant Power On: Special mode for quick boot up
CEC: Yes
Teletext: Yes
EPG: Yes (Only for DTV Programme)
Subtitle: Yes (Only for DTV Programme)
Parental Control: Yes (for DTV programme only)
USB PVR/Pause Live TV: Yes/Yes
Picture Modes: Vivid, Low Power, Smart HDR, Sports, Movie,
Game, PC
Aspect Ratio: 16:9/4:3/Cinerama/14:9 Zoom/16:9 Zoom/16:9
Zoom Up
Dynamic Brightness: Off/ECO/Brightness+
Motion Clarity: On/Off
Full Array: Yes
Overscan: On/Off
AiPQ Processor 3.0: Yes
Auto Format: On/Off
Sports Mode: Yes
Auto Low Latency Mode (ALLM): Yes
Wide Colour Gamut: Yes
Quantum Dot Technology: Yes
Variable Refresh Rate: Up to 144Hz
Freesync Premium Pro: Yes
IMAX Enhanced: Yes
CONNECTIVITY
Internet Connectivity: 2.4GHz + 5GHz dual-band Wi-Fi 802.11
a/b/g/n/ac Ethernet Network
Bluetooth: Yes.
Bluetooth 5.0
HDMI Inputs: 4 x HDMI Inputs (1.4b, 2.0 & 2.1) &
HDCP2.2
USB Inputs: 2 x USB 2.0
Headphone Output: Yes
AV IN: Yes
Optical SPDIF Output/HDMI eARC: Yes
eARC: Yes
USB DEVICE MEDIA FORMAT
Music: MP3/WMA/MKV/AVI
Picture: JPEG/PNG/BMP/WebP/HEIF Codec
Multimedia Video/Audio: Decoder H.264, H.265, MPEG1/2/4,
WMV, VC1, VP8, VP9, AV1
Video Format up to: Up to 4K@60Hz-10bit 4:2:2, 4K@60Hz-8bit
4:4:4
USB Mouse/Key Board Support: Yes
ACCESSORIES
Remote Control: RC902V Remote Control
Quick Start Guide: Yes
User Manual: Yes
DIMENSIONS & WEIGHT
Dimensions With Stand (mm): 1667 (W) x 1020 (H) x 330 (D)
Dimensions Without
Stand (mm): 1667 (W) x 960 (H) x 72 (D)
Carton Dimensions
(LxWxH mm): 1850 x 190 x 1125
Net Weight With Stand (Kg): 29.3
Net Weight Without Stand (Kg): 28.1
Gross Weight With Packaging (Kg): 41.3
WALL MOUNT VESA (PURCHASED SEPARATELY) VESA Hole Pattern:
400 x 400
Screw Size: M6 x 20 Screw Quantity (pcs) 4
SOUND Audio Power Output: 2×15W
Sound Modes:
Standard/Movie/Music/Voice/ Game/Sports/Dynamic Dolby Atmos: Yes
DTS Virtual: X :Yes
PANEL SPECIFICATION
Backlight Unit :DLED
Aspect Ratio: 16:9
Display Resolution: Ultra HD (3840×2160)
Brightness (cd/m2): 550 Nits
Contrast Ratio: 6000:1
Response Time (G to G): 6.5ms
Viewing Angle (H/V): 178°/178°
Clear Motion Rate (CMR): 200
Product SKU: TCL 75C745
